Parker PVP4136C9R211 PVP4836R2H21 PVP Series Pump

5out of5 based on4 reviews | Write a review
  • Model Number:PVP4136C9R211 PVP4836R2H21

    Nominal Displacement:16 23 33 41 48ml/R

    Rated Pressure:25mpa

    Maximum Pressure:35mpa

    Rated Speed:2400-3000r/Min

    Speed Range:600-3000r/Min

    Brand Name:Replacement  Parker  PVP Series Pump

    Warranty:1 Year

    Delivery Time: 7-25days

    Origin:China

    Minimum Order:1 Pieces

    Sample:Contact us for free samples

    Price:$857.14-$1428.56

Product Description

Offers original and replacement Parker PVP4136C9R211 PVP4836R2H21 PVP Series Pump for our customers.Save money, boost productivity, and increase your profits with our products. Get Latest Price now!

Parker PVP4136C9R211 PVP4836R2H21 PVP Series Pump

Variable Volume Displacement Piston Pump, Operating Pressure of 3,600 psi.

The PVP Series provides durable variable volume Piston Pumps for medium pressure applications. With aa pressure rating of 3,600 psi and a wide range of controls, PVP pumps are efficient and reliable. The PVP Series is flexible and high-performing, resulting in increased uptime with fast and reliable variable volume pumps engineered for medium pressure applications. PVP pump feature thru-shaft capability and high-strength construction for greater productivity, while improving the work environment with reduced noise levels and easy-to-service components.

Key Features:

  • Maximum operating pressure of 250 bar (3,600 psi)
  • Maximum speed of 2,400 rpm
  • Temperature range of -40 to 122 ºF (-40 to 50ºC)


Body MaterialCast Iron-
Case Drain OptionYes-
Charge Pump OptionNo-
Circuit TypeOpen-
ConfigurationSingle/Tandem/Multiple-
Control MethodPressure limiter / Load sense-
Energy Recovery CapableNo-
Filtration OptionNo-
Fluid TypeStandard Hydraulic Fluid-
Maximum Displacement48 cm³/rev2.9 in³/rev
Maximum Flow30.4 GPM115 LPM
Min./Max. Fluid Temperature-40°C to  50°C-40 ºF to 122°F
Maximum Noise Level 76 DBA-
Max. Operating Pressure (continuous) 250 bar3600 psi
Maximum Speed (RPM)2400-
Min./Max. Viscosity (SUS)NANA
Max. WeightNANA
MediaHydraulic-
Mounting OptionSAE-
Port ConnectionSAEFlange, Straight Thread
Porting LocationSide ports, rear ports, opposing ports-
Pump TechnoLogyPiston-
RotationClockwise, counter clcokwise-
Shaft TypeSAE-
Thru-drive CapabilityYes-

Product Image Gallery

Product Complete Model No.

PVP41362L211
PVP41362L26A211
PVP41362L26A411
PVP41362L2A11
PVP41362L2HLM11
PVP41362L2HLMV11
PVP41362L6A411
PVP41362R11
PVP41362R211
PVP41362R26A211
PVP41362R2A11
PVP41362R2H11
PVP41362R2HLM11
PVP41362R2M11
PVP41362R2P11
PVP41362R2V11
PVP41362RH11
PVP41362RHLM11
PVP41362RM11
PVP41362RV11
PVP41363R26A1VH10
PVP41363R26A411
PVP41363R26B111
PVP41363R6A211
PVP41363R6A2M11
PVP41363R6A411
PVP41363R6A4H11
PVP41363R6A4MV11
PVP41363R6B111
PVP41363R6B1A11
PVP41363R6B1P11
PVP41363R6B311
PVP41368R2P11
PVP41368RAP11
PVP41369L29B3A11
PVP41369L2A11
PVP41369L2AV11
PVP41369L2M11
PVP41369R211
PVP41369R29A411
PVP41369R2A11
PVP41369R2H11
PVP41369R2M11
PVP41369R2ME11
PVP41369R2MP11
PVP41369RH11
PVP41369RP11
PVP4136C3R26B1M11
PVP4136C3R26B211
PVP4136C3R26B311
PVP4136C3R6A111
PVP4136C3R6A1A11
PVP4136C3R6A2A11
PVP4136C3R6A4M11
PVP4136C3R6B111
PVP4136C3R6B211
PVP4136C9R211
PVP4136C9R29C3MD11
PVP4136C9R2H11
PVP4136C9R2M11
PVP4136C9R9B311
PVP4136C9R9B411
PVP4136C9RHLA11
PVP4136C9RM11
PVP4136D2L11
PVP4136D2R11
PVP4136D2R26A4M11
PVP4136D2R26B4A11
PVP4136D2R2A11
PVP4136D2R6A211
PVP4136D2R6A4A11
PVP4136D2R6A4AP11
PVP4136D2R6A4C11
PVP4136D2R6A4M11
PVP4136D2R6A4MP11
PVP4136D2R6B1M11
PVP4136D2R6B4A11
PVP4136D2R6B4AP11
PVP4136D2RA11
PVP4136D2RAP11
PVP4136D3L6A2A11
PVP4136D3L6A4A11
PVP4136D3LA11
PVP4136D3R6A111
PVP4136D3R6B3P11
PVP4136D3RA11
PVP4136D9L2A11
PVP4136D9LA11
PVP4136D9R211
PVP4136D9R29B311
PVP4136DL211
PVP4136DLC11
PVP4136DR211
PVP4136DRA11
PVP4136DRAP11
PVP4136DRC11
PVP4136DRM11
PVP4136DRP11
PVP4136K9L2A11
PVP4136K9L2M11
PVP4136K9R11
PVP4136K9R211
PVP4136K9R29A4A11
PVP4136K9R29A4M11
PVP4136K9R29B311
PVP4136K9R29B3A11
PVP4136K9R29B4M11
PVP4136K9R2A11
PVP4136K9R2C11
PVP4136K9R2H11
PVP4136K9R2M11
PVP4136K9R2V11
PVP4136K9R9A4C11
PVP4136K9R9B3A11
PVP4136K9RA11
PVP4136K9RHLA11
PVP4136K9RM11
PVP4136L11
PVP4136L211
PVP4136L2A11
PVP4136L2AV11
PVP4136L2M11
PVP4136L2P11
PVP4136L2VH10
PVP4136L2VM11
PVP4136LA11
PVP4136LP11
PVP4136R11
PVP4136R211
PVP4136R2A11
PVP4136R2H11
PVP4136R2HLM11
PVP4136R2M11
PVP4136R2ME11
PVP4136R2MP11
PVP4136R2P11
PVP4136R2V11
PVP4136R2VM11
PVP4136RA11
PVP4136RAP11
PVP4136RC11
PVP4136RH11
PVP4136RHP11
PVP4136RM11
PVP4136RP11
PVP4136RV11

PROVIDING EXCELLENT SOLUTIONS BY XingYing Hydraulic

When seeking manufacturers and suppliers for Parker PVP4136C9R211 PVP4836R2H21 PVP Series Pump, choosing XingYing Hydraulic is your wise decision.

We pride ourselves on high quality, diverse options, competitive pricing, and swift delivery.

Engage with our experts now to explore further insights into our Parker PVP4136C9R211 PVP4836R2H21 PVP Series Pump product solutions.

Request a Quote
