What should I pay attention to when using vane pumps?

Vane pump, is the rotor groove of the vane and pump casing (stator ring) contact, the suction of the liquid from the inlet side of the pressure to the discharge side of the pump. Vane pump management points in addition to the need to prevent dry rotation and overload, preventing suction air and suction vacuum is too large, should also be noted:

1. pump steering change, its suction and discharge direction also change vane pumps have provisions of the steering, not allowed to reverse. Because the rotor leaf groove has a tilt, blade has chamfered, blade bottom and oil discharge cavity through the oil distribution disk on the throttle groove and suction and discharge port is designed according to the established steering. Reversible vane pump needs special design.

2. Vane pump Assembly: the oil distribution plate and stator are correctly positioned with locating pins, the vane, rotor, oil distribution plate shall not be installed in reverse, the inner surface of the stator suction area is easy to wear, if necessary, it can be installed by turning it over, so that the original suction area becomes the discharge area and continues to be used.

3. Disassembly and Installation: pay attention to the working surface is clean, the work of the oil should be well filtered.

4. Pay attention to the clearance of the vane in the lobe groove is too large, it will make the leakage increase; if it is too small, the vane can't be free to expand and contract, it will lead to the work malfunction.

5. The axial clearance of the vane pump has a great influence on ηv. Small pumps for 0.015 ~ 0.03mm; medium-sized pumps for 0.02 ~ 0.045mm.

6. The temperature and viscosity of the oil should not exceed 55 ℃, generally should not exceed 55 ℃, viscosity requirements in the 17 ~ 37mm2 / s between.

For the use of vane pump precautions introduced here, I hope to help you.
